Vi har også noen få igjen i M10, M12, M16, M20 og M24 med kulelager. Disse har artikkelnummer som starter med 8-201-xxx.
Produkt nr. | WLL/tonn 5:1 |
WLL/tonn 4:1 |
Dreiemoment i Nm | Bolt størresle | E | A | B | D | F | G | Kg |
---|---|---|---|---|---|---|---|---|---|---|---|
8-203-005 | 0,45 | 0,55 | 16 | M10 x 1.50 x 45 | 11,5 | 40 | 41 | 9 | 102 | 65 | 0,5 |
8-203-005L | 0,45 | 0,55 | 16 | M10 x 1.50 x 60 | 26,5 | 40 | 41 | 9 | 102 | 65 | 0,5 |
8-203-019 | 1,90 | 2,40 | 81 | M16 x 2.00 x 65 | 19,0 | 65 | 64 | 15 | 158 | 105 | 1,8 |
8-203-021 | 2,15 | 2,70 | 136 | M20 x 2.50 x 70 | 24,0 | 65 | 64 | 15 | 158 | 105 | 1,9 |
8-203-021L | 2,15 | 2,70 | 136 | M20 x 2.50 x 90 | 44,0 | 65 | 64 | 15 | 158 | 105 | 2,1 |
8-203-030 | 3,00 | 3,75 | 136 | M20 x 2.50 x 80 | 25,0 | 85 | 79 | 19 | 204 | 134 | 4,2 |
8-203-030L | 3,00 | 3,75 | 136 | M20 x 2.50 x 100 | 45,0 | 85 | 79 | 19 | 204 | 134 | 4,2 |
8-203-042 | 4,20 | 5,25 | 312 | M24 x 3.00 x 80 | 25,0 | 85 | 79 | 19 | 204 | 134 | 4,2 |
